CRUSHER-SERIES

Double Tooth Roller Crusher

Double Tooth Roller Crusher
2023072803214393
2023081009291036
Double Tooth Roller Crusher
2023072803214393
2023081009291036

Double Tooth Roller Crusher

   What is Double Tooth Roller Crusher Double teeth roll crusher is mainly used in mining, metallurgy, chemical industry, coal mine to crush coarse, medium size fragile material. Its feeding ……

  • Feed size: 80-1050mm
  • Productive capacity:7-300t/h
  • Application:Construction waste, pebbles, bluestones, limestone, granite, basalt and other materials that need to be moved.
  • Application scope: It is suitable for crushing of raw coal (gangue containing) in coal, metallurgy, mining, chemical industry, building materials and other industries



What is Double Tooth Roller Crusher

Double teeth roll crusher is mainly used in mining, metallurgy, chemical industry, coal mine to crush coarse, medium size fragile material. Its feeding size is big, discharging size is adjustable. it can crush material of compressive strength below 160Mpa.



Double toothed roller crusher can crush materials

Especially in coal industry, double teeth roll crusher can crush raw coal and coke directly after removing iron and impurity, no need to remove gangue. crushed material is uniform granularity, low over crushing ratio. it simplified coal selecting process, reduced investment and production cost. Double teeth roll crusher can be equipped with coarse or medium sized teeth rollers according to material characteristics and requirements.

Working principle

The double-toothed roller sand making machine uses two wear-resistant alloy toothed rollers to break materials under high extrusion pressure generated by relative rotation. After the materials enter the gap between the two toothed rollers (V-shaped crushing chamber), the materials are broken into the required particle size and then sent out by the conveying equipment under extrusion, shearing and grinding.

Model

Feed size

 (mm)

Discharge size

(mm)

Capacity

(t/h)

2PGC400x250
80-100
10-50
7-15
2PGC400x400
180-260
10-50
15-30
2PGC450x500
300-500
15-100
30-60
2PGC600x750
300-600
20-120
60-100
2PGC600x900
300-600
30-150
80-120
2PGC900x900
600-900
30-200
150-200
2PGC900x1200
700-950
30-200
180-220
2PGC1200x1500
800-1050
30-200
200-300
