Mobile Roller Crusher

Mobile Roller Crusher

What is Mobile Roller Crusher To eliminate operational barriers caused by customer crushing sites and environments, and increase equipment mobility, we can provide the design and production of mobil……

Feed size: 25-100mm
Productive capacity:5-450t/h
Application:River pebble, calcite, quartzite, marble, pebble, bentonite, iron ore, bluestone, mountain stone, water slag, limestone, weathered sand, diabase, granite, basalt and so on
Application scope: Highway, railway, high-rise buildings, municipal, hydropower dam construction, concrete mixing station, sand and stone field, etc.

What is Mobile Roller Crusher

To eliminate operational barriers caused by customer crushing sites and environments, and increase equipment mobility, we can provide the design and production of mobile crushers.

Click on the link to view the video

product category:

The double roller crusher can be divided into large, medium, and small sizes according to different models.

Purpose and advantages

The integrated installation form of unit equipment eliminates the complex site infrastructure installation work of separated components, and reduces material and labor consumption. The reasonable and compact spatial layout of the unit enhances the flexibility of site stationed.
Mobile and flexible. This saves time for quick entry into the construction site, is more conducive to entering reasonable construction areas, and provides more flexible space and reasonable layout configuration for the overall crushing process.
The integrated series of mobile crushing stations can be used independently or provide more flexible process configurations tailored to customer requirements for material types and products in the process, meeting various requirements such as mobile crushing and screening, making production organization and logistics transportation more direct and effective, and minimizing costs.

Specification and model	Roll diameter (mm)	Feed size (mm)	Productive capacity (t/h)
2PGT400×250	φ400	≤25	2-10
2PGT400×400	φ400	≤25	5-12
2PGT610×400	φ610	≤30	5-20
2PGT750×500	φ750	≤30	10-40
2PGT800×600	φ800	≤40	12-50
2PGY800×800	φ800	≤40	40-50
2PGY800×1000	φ800	≤40	50-80
2PGY1000×800	φ1000	≤40	50-80
2PGY1000×1000	φ1000	≤40	80-100
2PGY1200×1000	φ1200	≤60	100-120
2PGY1200×1200	φ1200	≤60	120-150
2PGY1500×1000	φ1500	≤80	150-200
2PGY1500×1200	φ1500	≤80	200-250
2PGY1800×1000	φ1800	≤100	250-300
2PGY2000×1200	φ2000	≤120	300-400
